Long Arm Spread, High Precision, Reliability CIANSUNG Robot CR-4iA

CIANSUNG Robot CR-4iA is a small collaborative robot that is similar in size to a human arm. With a handling mass of 4 kg and a reachable radius of 550 mm, it is suitable for assembly of parts and handling of workpieces. It can be mounted by hanging or wall mounting to save space. It meets the requirements of human-robot cooperative operation without a safety fence, and the human and robots can share the same area for operation.

    oops...!

    no product data.

    Go to homepage
    2 (36)

    Minimal Deployment - Space Revolution

    Zero-foundation modification: Support wall/ceiling/production line gap embedded installation, saving 30% production line area.

    Plug and play: 2 hours of rapid deployment, adapted to the AGV mobile platform to create flexible production lines.


    Human-machine integration - intelligent safety.

    Dynamic obstacle avoidance: real-time sensing of human body approach, automatic speed reduction or pause.

    Collision rebound: haptic feedback sensitivity ≤5N, emergency stop response <0.1 second.



    Collaborative Robot CR-4iA

    Model

    CR-4iA

    DOF

    6

    Rated Payload

    4kg

    Repeatability

    ±0.01mm

    Tool Max Speed

    3m/s













    Max Speed

    axis-J1

    150°/s

    axis-J2

    150°/s

    axis-J3

    210°/s

    axis-J4

    240°/s

    axis-J5

    240°/s

    axis-J6

    240°/s

    Noise level

    ≤60dB

    Ambient Temperature

    0℃-50℃

    Ambient Humidity

    5%-90%RH,(non-condensing)

    Mounting

    (Arbitrary angle)

    Protected Structure

    IP64

    Industrial application industry

    Automobile, 3C, machinery manufacturing, energy, hardware appliances, food, daily chemicals, semiconductor, textile, sanitary ware, agriculture, new retail, health care, scientific research and education.

    Various application scenarios

    Screw locking, riveting, hot forging, spraying, gluing, deburring, loading and unloading, welding, material sorting, palletizing, labeling, flexible assembly, intelligent surgical lamp.
